gefran ADV200 Functions Description And Parameters List page 265

Menu PAR Description
27.8.1 222 Theta src
27.8.2 226 Flux ref src
27.8 - SERVICE/CURRENTS
27.8.1 80 Phase current U
27.8.2 82 Phase current V
27.8.3 84 Phase current W
27.8.4 90 Phase current RMS U
27.8.5 92 Phase current RMS V
27.8.6 94 Phase current RMS W
ADV200 • Parameters List
UM Type FB BIT Def
LINK 16/32BIT
L_THETASEL
LINK 16/32BIT
L_FLUXREFSEL
A FLOAT
A FLOAT
A FLOAT
A FLOAT
A FLOAT
A FLOAT
Min Max
220 0
224 0
0.0 0.0 0.0
0.0 0.0 0.0
0.0 0.0 0.0
0.0 0.0 0.0
0.0 0.0 0.0
0.0 0.0 0.0
Acc Mod
16384 ERW
16384 ERW
ER FVS
ER FVS
ER FVS
ER FVS
ER FVS
ER FVS
265
