APPENDIX 1.
APP. 1.1 - Use of analog and digital I/Os from the MDPLC programming environment
• The following table shows the internal and variable system parameters for External digital input exp.
DIGITAL INPUT EXP
Name
sysEDIBitWord
sysEDIBitWordBit0
sysEDIBitWordBit1
sysEDIBitWordBit2
sysEDIBitWordBit3
sysEDIBitWordBit4
sysEDIBitWordBit5
sysEDIBitWordBit6
sysEDIBitWordBit7
SysEDIBitWordBit8
SysEDIBitWordBit9
SysEDIBitWordBit10
SysEDIBitWordBit11
SysEDIBitWordBit12
SysEDIBitWordBit13
SysEDIBitWordBit14
SysEDIBitWordBit15
sysExtIODigIn0
sysExtIODigIn1
• The following table shows the internal and variable system parameters for External analog input exp.
Analog input modules can have a resolution of 12 to 16 bits and scaling may vary from manufacturer to manu-
facturer.
E.g.:
12-bit module
Signal connected
Module configuration
-10V..+10V
0V..+10V
4..20mA
276
Type Description
DWORD Exp Digital input word
Scheme: "Digital Inputs"
BOOL Exp Digital input 0 (0..1)
Scheme: "Digital Inputs"
BOOL Exp Digital input 1 (0..1)
Scheme: "Digital Inputs"
BOOL Exp Digital input 2 (0..1)
Scheme: "Digital Inputs"
BOOL Exp Digital input 3 (0..1)
Scheme: "Digital Inputs"
BOOL Exp Digital input 4 (0..1)
Scheme: "Digital Inputs"
BOOL Exp Digital input 5 (0..1)
Scheme: "Digital Inputs"
BOOL Exp Digital input 6 (0..1)
Scheme: "Digital Inputs"
BOOL Exp Digital input 7 (0..1)
Scheme: "Digital Inputs"
BOOL Exp Digital input 8 (0..1)
Scheme: "Digital Inputs"
BOOL Exp Digital input 9 (0..1)
Scheme: "Digital Inputs"
BOOL Exp Digital input 10 (0..1)
Scheme: "Digital Inputs"
BOOL Exp Digital input 11 (0..1)
Scheme: "Digital Inputs"
BOOL Exp Digital input 12 (0..1)
Scheme: "Digital Inputs"
BOOL Exp Digital input 13 (0..1)
Scheme: "Digital Inputs"
BOOL Exp Digital input 14 (0..1)
Scheme: "Digital Inputs"
BOOL Exp Digital input 15 (0..1)
Scheme: "Digital Inputs"
DWORD External expansion digital input 0
This parameter displays the state of
external inputs from 0 to 31
DWORD External expansion digital input 1
This parameter displays the state of
external inputs from 32 to 63
Variant 1
-2048..+2047
0..+4095
0..+32767
Unit
Null
Null
Null
Null
Null
Null
Null
Null
Null
Null
Null
Null
Null
Null
Null
Null
Null
Null
Null
Variant 2 Variant 3
-32768..+32767 -16384..+16383
0..+2047 0..+32767
+6553..+32767 +3276..+16383
R/W
1200 R
1210 R
1212 R
1214 R
1216 R
1218 R
1220 R
1222 R
1224 R
5510 R
5512 R
5514 R
5516 R
5518 R
5520 R
5522 R
5524 R
5400 R
5402 R
Variant 4
0..+65535
