  • Page 1 ADV200 / ADV200 WA En g lish /It alian o ..Quick Startup Manual R-PSM card Addendum...
  • Page 2 Before using the product, please read the chapter on safety instructions carefully. Keep the manual in a safe place and available to technical personnel during the product functioning period. Gefran S.p.A. reserves the right to make changes and variations to products, data and dimensions at any time without notice.
  • Page 3: Table Of Contents

    5.2.5.4 Jumpers ............................. 17 5.2.5.5 Led scheda R-PSM ........................18 5.2.5.6 Scheda di regolazione alimentatore (solo per taglie ≥ 71600). Drive con S/N precedenti a S/N: 34GG044151 ..........................19 Addendum to the ADV200 / ADV200WA QS Instruction books Page 3 of 20...
  • Page 4: Introduction

    1. Introduction This document can be used as addendum to the existing ADV200 / ADV200 WA QuickStartups. It indicates informations about new chapters updating. Addendum to the ADV200 / ADV200WA QS Instruction books Page 4 of 20...
  • Page 5: Modified Chapters

    ADV200-…-4 = 400VAC / 50Hz ADV200-…-6 = 690VAC / 50Hz the settings should not be changed. In case of non-standard power supply, see the configuration tables shown further below. Addendum to the ADV200 / ADV200WA QS Instruction books Page 5 of 20...
  • Page 6: Behavior Of Pre-Charge Ok Relay-Digital Out 1, Digital Out 2 At "Poweron" And "Poweroff

    (min) Terminal strip (AWG) (mm) (Nm) 0.2 ... 2.5 24 ... 12 5.2.5.2 Behavior of Pre-charge OK Relay-Digital Out 1, Digital Out 2 at “PowerOn” and “PowerOff” Addendum to the ADV200 / ADV200WA QS Instruction books Page 6 of 20...
  • Page 7: R-Psm Card Configuration Switches

    The relay between terminals 70 – 72 closes at the end of the pre-charge phase and opens when DC voltage drops below the DC Undervoltage threshold. Wiring of the OK relay contact (70 - 72) in series with the Enable chain of the ADV200 regulation card is recommended.
  • Page 8 1) Keep the default configuration of switches S2-2…4 and connect an current probe to output C or D of the ADV200 module. The probe must be able to measure a peak current ≤ 10[ms].
  • Page 9: Jumpers

    5.2.5.4 Jumpers The configuration of the configuration Jumpers can be changed ONLY by Gefran personnel. Unauthorized changes will invalidate the warranty. Jumper Function Default FPGA manual reset OPEN Disables heatsink overtemperature monitor OPEN Enables function of 230VAC line power supply...
  • Page 10: Power Supply Unit R-Sm3-Adv Regulation Card (Only For Sizes ≥ 71600) For Drive S/N Previous Than S/N

    AC11) The jumpers shown are factory-wired. Note! Wiring of the OK relay contact (70 - 72) in series with the Enable chain of the ADV200 regulation card is recommended. Addendum to the ADV200 / ADV200WA QS Instruction books Page 10 of 20...
  • Page 11 (see the alarm conditions described above) or when the power supply is switched off and the DC- LINK is completely discharged (C and D terminals). Addendum to the ADV200 / ADV200WA QS Instruction books Page 11 of 20...
  • Page 12: Introduzione

    3. Introduzione Questo documento può essere usato come addendum ai già esistenti manuali ADV200 / ADV200 WA QuickStartup. Sono presenti informazioni di aggiornamento di alcuni capitoli. Addendum to the ADV200 / ADV200WA QS Instruction books Page 12 of 20...
  • Page 13: Capitoli Modificati

    300ms, tempo necessario al circuito di phase loss per verificare che siano tornate le con- dizioni di rete nominali. R-PSM card Figure 5.2.5.1: Posizione di Switch, LEDs e Jumpers sulla scheda R-PSM Addendum to the ADV200 / ADV200WA QS Instruction books Page 13 of 20...
  • Page 14: Ingressi/Uscite Scheda Di Regolazione R-Psm

    250Vac - 30Vdc - 0.5A Sezione dei cavi (conduttore flessibile) Spelatura consigliata Coppia di serraggio (min) (min) Morsettiera (AWG) (mm) (Nm) 0.2 ... 2.5 24 ... 12 Addendum to the ADV200 / ADV200WA QS Instruction books Page 14 of 20...
  • Page 15: Comportamento Di Relè Precharge Ok, Digital Out 1, Digita Out 2 Al "Power On" E "Power Off

    La scheda R-PSM dispone di 3 switch di configurazione a 4 posizioni. Nelle tabelle successive sono indicate tutte le possibili combinazioni ammesse. Legenda: OPEN CLOSE (*) Impostazione di Default modelli ADV200-...-4. (**) Impostazione di Default modelli ADV200-...-6. Addendum to the ADV200 / ADV200WA QS Instruction books Page 15 of 20...
  • Page 16 è il banco di condensatori collegato al DC link maggiore è l’energia da trasferire, nel caso fosse necessario ottenere un tempo di precarica inferiore alla configurazione di default, è necessario seguire la seguente procedura di verifica: Addendum to the ADV200 / ADV200WA QS Instruction books Page 16 of 20...
  • Page 17: Jumpers

    1) Mantenere la configurazione di default degli switch S2-2…4 e collegare una sonda amperometrica sull’uscita C o D del modulo ADV200. La sonda deve essere in grado di rilevare un picco di corrente ≤ 10[ms]. 2) Alimentare e abilitare il ponte di precarica misurando il valore della corrente di picco assorbita.
  • Page 18: Led Scheda R-Psm

    Bit S2: codifica lo STATO dell’alimentatore (MSB) GIALLO Ponte SCR bridge abilitato GIALLO Per la posizione dei Jumper vedere la “Figura 5.2.5.1: Posizione Switches, Led e Jumper sulla scheda Note! R-PSM”. Addendum to the ADV200 / ADV200WA QS Instruction books Page 18 of 20...
  • Page 19: Scheda Di Regolazione Alimentatore (Solo Per Taglie ≥ 71600). Drive Con S/N Precedenti A S/N

    I jumper indicati sono già cablati in fabbrica. Si consiglia di cablare il contatto del Relè di OK (70 - 72) Note! in serie alla catena dell’Abilitazione della regolazione di ADV200. Addendum to the ADV200 / ADV200WA QS Instruction books...
  • Page 20 è interrotta e il DC-LINK è completamente scarico (morsetti C e D). Addendum - code 1S9O01A (rev. 0.1 – 22-4™-2015) Addendum to the ADV200 / ADV200WA QS Instruction books Page 20 of 20...
