Chapter 4: F2000 Customer Replaceable Units (CRUs)
Rack Rails Replacement
Remove and Install
Rack Rails
Figure 153 IPMI/BMC Port
Location on the Top Canister
148
To remove rack rails:
Removing and installing a chassis requires you to complete the
following procedures in the order presented:
1 Power Off the System
2 Disconnect the Cables from the System
3
Remove the Chassis from the Rack
4 Remove the Old Rack Rails and Install the New Rack Rails
page 157
5 Install the Chassis into the Rack
6 Connect the Cables to the System
7 Verify the System is Up and Running
8 Install the Bezel on page 170
Power Off the System
To power off the system:
1 Using an Ethernet cable, connect a notebook computer to IPMI/BMC
port on the top canister (see
Item
1 IPMI/BMC port on the top canister
2 Access the BMC Web UI.
on page 148
on page 151
on page 155
on page 163
on page 165
on page 169
Figure 153).
Description
Quantum F2000 User's Guide
