Cable Connections

1-4-1
Preliminaries
1. The following interconnection cable numbers refer to the MIS MAP and GROUNDING
INTERCONNECTING MAP included at the end of this manual.
2. The reference numbers between brackets ( ) refer to internal cables also described in the Service
Manuals.
1-4-2
Mis Chart
System MPH 50/65/80 with Compax 40E / SG 60 or SG100 / XT Suspension
Note: Some of the cables, or set cables, are factory connected at one end. In the following MIS Charts:
Numbers on the left presented in grey squares are HLA numbers (CABLES #).
The : symbol is used to identify those connections which remain to be done during on site
installation.
The H symbol indicates where cable clamping is necessary (refer to Job Card IST006 of this Manual
for EMC rules requirements.
System Service Manual − SYSTEM COMPAX 40E, CE Marked
with MPH 50/65/80 (including XT, RS 85 and Tomo−Link)
DO NOT FORGET TO CLAMP CABLES ENTERING THE MPH CABINET. IT IS
MANDATORY TO MAINTAIN THE SYSTEM EMC COMPLIANT.
