X−RAY TUBE & COLLIMATOR
INSTALLATION ON XT SUSPENSION
ILLUSTRATION 3
X−RAY TUBE
REMARK:
System Service Manual − SYSTEM COMPAX 40E, CE Marked
THE COLLIMATOR INTERFACE PLATE IS ADJUSTED IN FACTORY (HLA)
with MPH 50/65/80 (including XT, RS 85 and Tomo−Link)
Job Card IST 001
FIXING SCREWS
COLLIMATOR INTERFACE PLATE
(ULTRANET SA & SM)
68
DIRECTION 2154260−100
2 of 8
