GE HEALTHCARE
REV 9
Rotation of the Tube Unit/Collimator Assy
Knobs, Buttons, Sensitive Handle
Light Beam Centering Device
Tape Measure
SECTION 3
PERFORMANCE TESTS
MPH
Tomo−Link
IQ (including AEC)
System Service Manual − SYSTEM COMPAX 40E, CE Marked
with MPH 50/65/80 (including XT, RS 85 and Tomo−Link)
See SM 2137354−100, Job Card VF002
See Dir 2133821−100, Chapter 18−10
See Tomo−Link, Chapter 18−10
See SG 60 SM 2150293−100; VF01
See SG 100 SM 2150297−100; VF01
87
Chapter 3
Chapter 4
Chapter 4
DIRECTION 2154260−100
page 3−6
page 4−13
page 4−16
