GE HEALTHCARE
REV 9
X−RAY TUBE & COLLIMATOR
INSTALLATION ON XT SUSPENSION
ILLUSTRATION 2
XT Control Board
(2146642 B)
System Service Manual − SYSTEM COMPAX 40E, CE Marked
with MPH 50/65/80 (including XT, RS 85 and Tomo−Link)
Job Card IST 001
24V Test Point (J10)
AC
26V Test Point (J11)
AC
Common Test Point
64
DIRECTION 2154260−100
2 of 4
