GE HEALTHCARE
REV 9
SYSTEM COMPAX 40E
Purpose: X−RAY TUBE & COLLIMATOR
INSTALLATION ON XT SUSPENSION
Time:
SECTION 1
SPARES REQUIRED
MX100 Tube
SECTION 2
EQUIPMENT REQUIRED
Protective pad, metal rod.
SECTION 3
SAFETY PRECAUTIONS
None
SECTION 4
PRELIMINARY STEPS
None
SECTION 5
INSTALLATION PROCEDURES
The following procedure describes the steps for replacing an MX100 Tube.
System Service Manual − SYSTEM COMPAX 40E, CE Marked
with MPH 50/65/80 (including XT, RS 85 and Tomo−Link)
NEVER REMOVE THE ROD DURING X−RAY TUBE (OR COLLIMATOR)
REPLACEMENT UNTIL STEP 8. OF THIS PROCEDURE
Follow these instructions carefully and read the procedure through before
starting work.
83
DIRECTION 2154260−100
Job Card IST 001
Version No.: 1
Date: February 10, 1997
Personnel:
1
1 of 4
