GE Compax 40E System Service Manual page 34

Table of Contents

Advertisement

GE HEALTHCARE
REV 9
Step
From previous page
WARNING
CONFIGURATION CHECK
D Bucky Voltage Settings:
A23
D 110 or 220AC for SG60−100 Bucky
D 110 or 220AC for Compax 40E Bucky
D 220V for XT Suspension, RS85, C40E,
TLK, SG
1 Person
VERY IMPORTANT: Read Inspection Report (IR) ( Dir. 21722166TDR for Compax 40E/MPH/SG/RS 85; Dir.
2167647TDR for Compax 40E/MPH SG/XT; Dir. 2179651TDR for Compax 40E/MPH/SG/Tomo−Link) through
carefully before eventually proceeding with the MPH software configuration, Step A24 of this Steering Guide.
D CALIBRATION OF SYSTEM COMPONENTS
Yes
System Service Manual − SYSTEM COMPAX 40E, CE Marked
Description
POWER ON AUTHORIZED
IR
meets
expectations?
No
Continues on next page
with MPH 50/65/80 (including XT, RS 85 and Tomo−Link)
Í Í
Mark each box when done
Í Í
Done
Supporting Documents
*
For Bucky: refer to Inspection Report 2179651
TDR, section, 4.2 for 40E, section 6.3 for SG
Í Í
For components: refer to Inspection Report
Í Í
2179651 TDR or 2167647 TDR or 2172166
TDR
Reconfiguration is complete.
If more reconfiguration is necessary, proceed to step A24
23
DIRECTION 2154260−100
MAINLY FOR USE IN THE USA:
or to Inspection Report 2167647 TDR or
2172166 TDR, section 4.2 for 40E; section
5.3 for SG
Refer also to orange label fixed to the Bucky
See IST 004
