GE HEALTHCARE
REV 9
X−RAY TUBE & COLLIMATOR
INSTALLATION ON XT SUSPENSION
5.2
Cable Connections (MIS 27239) and Conduit Routing
1. Secure stator cable shield to fan mounting bracket using the supplied clamp, bolt and nut.
Connect stator leads to the terminal strip as indicated in the MIS map and MIS chart MIS
27239 of this Manual.
To route the stator cable correctly, refer to RS 85 Mounting Instructions, Dir 03277223,
Chapter 1, section 1−4−3.
(Position 1 of terminal strip on X−ray Tube is on anode side).
5.3
Collimator Installation
1. Rotate the X−ray Tube Support so the bottom side of the tube unit is facing up.
2. Fasten the Collimator over to the X−Ray tube.
System Service Manual − SYSTEM COMPAX 40E, CE Marked
with MPH 50/65/80 (including XT, RS 85 and Tomo−Link)
THE COMMON LEAD ON THE MPH STATOR CABLE IS NOT GROUNDED.
CONNECT GROUND CABLE PROVIDED ON RS 85 TO X−RAY TUBE
HOUSING.
LOTITE THREADLOCKER MUST BE APPLIED DURING INSTALLATION TO
PREVENT THE SET SCREWS FROM BACKING OUT OVER TIME.
WARNINGS ARE ALL BOLD CAPS.
INSTALL AND TIGHTEN THE THREE SET SCREWS (DOWELS) INTO
COLLIMATOR LOCKING RING.
71
DIRECTION 2154260−100

Job Card IST 001

5 of 8
