GE Compax 40E System Service Manual page 41

GE HEALTHCARE
REV 9
Step
D FUNCTIONAL CHECKS
DD SYSTEM CHECKS
SYSTEM COMPONENT
FUNCTIONAL CHECKS
D SG60/SG100
D Collimator SA/SM
A39
D Compax 40E
D XT/RS 85
D MPH 50−65−80
D Tomo−Link
D Program−X
2 People
DD IMAGE QUALITY
D SG60−100 Film Resolution
D Tomo−Link Image Quality
A40
D 40E Film Resolution
2 People
Continues on next page
System Service Manual − SYSTEM COMPAX 40E, CE Marked
Description
From previous page
4 Hours
CHECKS
4 Hours
with MPH 50/65/80 (including XT, RS 85 and Tomo−Link)
Í Í
Í Í
Done
Supporting Documents
Refer to Inspection Report 2167647 TDR,
sections 1.2 & 1.5 (MPH), 4.11 (40E), 3.4
(XT/Collimator), 5.4 (SG60/100), 7 (general system
functional check)
or
Refer to Inspection Report 2179651 TDR,
sections 1.2 & 1.5 (MPH), 4.11 (40E), 3.4
(XT/collimator), 5.3 (Tomolink), 6.4 (SG60/100),
8 (general system functional check)
or
Inspection Report 2172166 TDR, sections 3.3
(RS 85/collimator), 4.12 (40E), 1.2 & 1.5 (MPH),
5.4 (SG60/100)
SG60/SG100 Dir 2150297−100
ULTRANET Collimator SM Dir.Y00W1L.04;
SM COMPAX 40E CE, Dir. 2150299−100,
Chapter 4, Section 3−4.;
XT sm Dir. 2118733−100;
RS 85 sm Mounting Instructions 03277223;
MPH SM Dir.2137354−100
SM ULTRANET SA & RAFL−S, Dir. Y00W20L.04,
Chapter 4;
Í Í
SM Tomo−Link 2133821−100 (section 18)
Refer to SG60 SM Dir 2150293−100, Job Card
SG100 SM Dir 2150257−100, Job Card VF001,
Í Í
Tomo−Link SM Dir 2133821−100 section 18−10
Í Í
Refer to 40E Service Manual 2150299−100,
30
DIRECTION 2154260−100
VF001,
Jobcard VF001.
