GE Compax 40E System Service Manual page 101

GE HEALTHCARE
REV 9
ILLUSTRATION
SYSTEM CABINET UPPER PART (2146714)
ITEM
PART NO.
NO.
− 2175225
− 2153822
− 2153823
−
1 2152751
2 2150568
3 2150565
4 2179445
2206408
−
− 2145602−2
− 2167144−2
− 2140362−2
− 2145651−2
− 2145618−2
− 2145655−2
− 2128497−2
− 2145602−3
− 2167144−3
− 2140362−3
− 2145651−3
− 2145618−3
− 2145655−3
− 2128497−3
Note:
System Service Manual − SYSTEM COMPAX 40E, CE Marked
FRU REP
1 2 3 4 5
2 S SYSTEM CABINET FRONT DOOR ASSY
2 S S 255 X 900 X 10 MM ALU AIR FILTER
2 S S DOOR LOCK
N S RAD OPTION
2 S S MAINS EMI FILTER 2P A6 250 V
2 S S INTERMEDIATE PANEL FOR RAFL−S OPTION
1 S S RAFL−S RACK CE MARKED (OPTIONAL)
1 S S LOW VOLTAGE POWER SUPPLY FOR RS 85 TUBE STAND OPTION
2 S S EMC TIE−WRAPS (BAG)
S SYSTEM CABLES
2 N S S 18M 40E SYSTEM BUCKY CABLE
2 N S S 18M 40E SYSTEM POWER CABLE
2 N S S 18M 40E SYSTEM GROUND CABLE
2 N S S 18M 40E SYSTEM AEC−MPH CABLE
2 N S S 18M 40E SYSTEM CASSETTE TRAY CABLE
2 N S S 18M 40E SYSTEM SID CABLE
2 N S S 18M STATOR CABLE
2 N S S 24M 40E SYSTEM BUCKY CABLE
2 N S S 24M 40E SYSTEM POWER CABLE
2 N S S 24M 40E SYSTEM GROUND CABLE
2 N S S 24M 40E SYSTEM AEC−MPH CABLE
2 N S S 24M 40E SYSTEM CASSETTE TRAY CABLE
2 N S S 24M 40E SYSTEM SID CABLE
2 N S S 24M STATOR CABLE
Other spare parts are sub−systems. Spare parts are found in
sub−system service manual (Chapter Spare Parts).
with MPH 50/65/80 (including XT, RS 85 and Tomo−Link)
DESCRIPTION
90
DIRECTION 2154260−100
QTY
1
1
1
1−2
1−2
1
1
1
1
1
1
1
1
1
2
2
2
2
2
2
2
A
P
P
