■ ■ ■ ■ ■ "MEMORY" → ...
"MEMORY" → → → → → "SAVE RAM"
The function save RAM is usually not needed since
the programs and parameters are automatically
saved.
With → "SAVE RAM" you can also save the current
array values in the EEPROM. "SAVE RAM" corre-
sponds to the command SAVEPROM, since all pro-
grams, parameters and arrays are saved.
"MEMORY" → → → → → "DELETE EEPROM"
Delete the EEPROM in the SyncPos option if you
either want to undo the array definition or want to
reset all parameters to the factory settings.
NB!
When you delete the EEPROM all parameters
are reset to the factory settings. However, this
is only done after the VLT has been turned off.
NB!
Remember the following when you delete the
EEPROM:
• Check whether you have saved all the neces-
sary programs on the computer so that you
can load these into the VLT again once the
EEPROM has been deleted.
• Check whether you have saved the parameters
for all the VLTs connected in a file on the com-
puter.
• Click on "MEMORY" → "DELETE EEPROM".
• Re-load the user parameters and the neces-
sary programs in the VLT resp. VLTs.
64
Programmable SyncPos motion controller
■ ■ ■ ■ ■ "RESET" → ...
"RESET" → → → → → "PARAMETERS"
With "RESET" → → → → → "PARAMETERS" all global para-
meters and all axis parameters in the SyncPos
motion controller are reset to the factory settings.
"RESET" → "ARRAYS"
With "RESET" → "ARRAYS" you can delete all
arrays in the RAM without – as was formerly the
case – deleting the parameters etc. This new com-
mand has the same effect as the menu command
DELETE ARRAYS.
NB!
If you then carry out SAVE ARRAYS, the
arrays in the EEPROM are also overwritten!
"RESET" → → → → → "COMPLETE"
With "RESET" → → → → → "COMPLETE" not only are all para-
meters, but also the programs and arrays are erased
and the SyncPos option is reset to the basic factory
setting ... ... ... ... ...
NB!
... ... ... ... ... and this happens immediately – not only
after the controller has been turned on and off
as is the case when you delete EEPROM.
