■ ■ ■ ■ ■ DEC
The DEC command defines the deceleration for
the next motion command (speed control, synchro-
nization or positioning). The value will remain valid
until a new deceleration value is set with another
DEC command. The value is related to the para-
meters Shortest ramp Shortest ramp RAMPMIN (31) and Shortest ramp Shortest ramp
Shortest ramp
Maximum velocit Maximum velocit Maximum velocity y y y y VELMAX (1) as well as V V V V V elocit Maximum velocit Maximum velocit
resolution resolution resolution VELRES (22). resolution resolution
N B!
If you work with the SyncPos option card
then you should always set the ramps via
the option card and not in the VLT. The VLT ramps
must always be set to minimum.
Summary
sets deceleration
Syntax
DEC a
Parameter
a = deceleration
N B!
If deceleration is not defined previous to the
positioning command then deceleration will
be the setting (negative) of parameter Default
acceleration acceleration DFLTACC (34). acceleration
acceleration acceleration
Command group
REL, ABS
Cross Index
ACC
Parameter: RAMPMIN (31), VELMAX (1), VELRES
(22)
Syntax-Example
ACC 50 /* acceleration: 50, while braking 10 */
DEC 10
Example
minimum acceleration time: 1000 msec
maximum velocity:
velocity resolution:
106
elocity y y y y elocit elocit elocit
Default Default Default Default
1500 Rpm
100
Programmable SyncPos motion controller
■ ■ ■ ■ ■ DEFMCPOS
DEFMCPOS defines the initial position of the
master (in MU) in the CAM-Mode and thus the
point where the curve begins as soon as the
master pulses are being counted.
Summary
Define initial position of the master
Syntax
DEFMCPOS p
Parameter
p = position in Master Units (MU)
Command group
CAM
Cross Index
DEFMORIGIN, SETMORIG IN, SYNCC
Parameter: SYNCMSTART
Syntax example
DEFMCPOS 1000
// Set internal MU counter to 1000
