Programmable SyncPos motion controller
This instruction manual covers two versions of the programmable SyncPos motion controller:
Ordering number
175Z0833
175Z3029
175Z3683
175Z3684
The basic functionality of the two versions is the same, the only differences are:
•
The Flux version has two additional outputs on the VLT5000Flux control card.
•
The Flux version does not yet support absolute encoders.
This instruction manual is valid for the following software versions:
© Danfoss A/S 2004
VLT is a registered Danfoss trademark.
IBM is a registered trademark of International Business Machines, Inc.
Microsoft, MS, MS-DOS, Microsoft NT, Windows and Wingdings are either registered trademarks or
trademarks of the Microsoft Corporation in the USA and/or other countries.
2
for
®
VLT 5000 and
®
VLT 5000Flux
Description
SyncPos for VLT5000
SyncPos for VLT5000 with conformal coating
SyncPos for VLT5000Flux
SyncPos for VLT5000Flux with conformal coating
SyncPos PC software version 6.5X
VLT5000/SyncPos software version 3.7/5.0X
VLT5000Flux/SyncPos software version 5.XX/5.0X
Programmable SyncPos motion controller
MG. 1 0.J8.02 – VLT is a registered Danfoss trade mark
Type code
A10 C0
A10 C1
A10 C0
A10 C1
