59 SYNCMPULSS
SYNCMPULSS defines how many qc (slave) lie
between two markers (slave) or in CAM-Mode the
distance of the sensor to the working position in
U U .
SYNCMPULSS is only valid for synchronization with
slave marker correction (SYNCM and SYNCCMS).
Content
Marker interval slave (marker distance slave)
or in CAM-Mode the distance of the sensor to the
working position in UU.
Parameter Group
Axis parameter Synchronization AXS
CAM-Editor: index card Synchron.
Unit
q c
in CAM mode: UU
Value range
0 ... 2* MLONG / 9
196
Programmable SyncPos motion controller
60 SYNCMTYPM
Defines the signal resp. the marker type for the
master: Index pulse of the encoder or external
marker.
SYNCMTYPM is only valid for synchronization with
marker correction (SYNCM and SYNCCMM) or if
you want to use the command MIPOS in your
program.
Master marker signal: Input 5.
Content
Marker type for master
Parameter Group
Axis parameter Synchronization AXS
CAM-Editor: index card Synchron.
Cross reference
MIPOS, SYNCMTYPS
Value range
0 ... 3
★ 500
0 = index pulse (positive flank)
1 = index pulse (negative flank)
2 = external marker (positive flank)
3 = external marker (negative flank)
61 SYNCMTYPS
Defines the signal resp. the marker type for the
slave: Index pulse of the encoder or external marker.
SYNCMTYPS is only valid for marker synchroniza-
tions (SYNCM).
Slave marker signal: Input 6
Content
Marker type slave
Parameter Group
AXS
Cross reference
IPOS, SYNCMTYPM
Value range
0 ... 3
0 = index pulse (positive flank)
1 = index pulse (negative flank)
2 = external marker (positive flank)
3 = external marker (negative flank)
