■ ■ ■ ■ ■ "SAVE" and "SAVE AS"
"FILE" → "SAVE"
Click on "FILE" → → → → → "SAVE" or on the
order to save a new or changed program on the
computer's hard drive from time to time or before
closing the file. If you have not yet saved a new
program file the corresponding window is automa-
tically opened under "FILE" → → → → → "SAVE AS".
Click on "FILE" → → → → → "SAVE AS" in order to save a
new or altered program under a new name. All
program files have the extension .m
NB!
You should always save your files on the PC.
This is because although the program is also
automatically saved for every execute and for each
syntax check in the SyncPos-Option, at this point the
program has already been compiled and thus can
no longer be altered in the computer.
For reasons of compatibility between Windows '95
and earlier versions of Windows the input of more
than 8 characters for the file names is not allowed.
You can save as many program files as will fit in
the free memory on the hard drive of the computer.
■ ■ ■ ■ ■ Printing and printer settings
"FILE" → "PRINT"
To print the file click on "FILE" → → → → → "PRINT", choose
the area to be printed and the desired number of
copies and start the printer with "OK".
The dialog field that appears is somewhat different
depending on your operating system – Windows
95 or Windows NT. For further information please
refer to the Windows help.
Click on "PRINT SETUP..." (or "PROPERTIES"), if
you want to set other factors such as paper format
or alignment (horizontal or vertical). These settings
can also be reached by clicking on "PRINTER
SETTINGS".
Click on → → → → → "PRINTER SETTINGS", if you want to
set the paper size, the output size (scaling) or other
options. You can find more information on the pos-
sibilities for Window's "PRINTER SETUP" in the
Windows help.
52
Programmable SyncPos motion controller
■ ■ ■ ■ ■ "EXIT PROGRAM"
Ending SyncPos
icon in The SyncPos program can be ended by clicking
on "EXIT PROGRAM" or on the ⌧ icon. If you have
not yet saved a new file or changes to an old file,
then you will have the chance to do this.
abort or end a program with [ESC]. In order to do
.m .m. .m .m this the file which is linked with the controller resp.
VLT must be open or re-opened.
that the VLT is sending PRINT commands which can
no longer be displayed by the communications
window.
■ ■ ■ ■ ■ Delete file
You can delete one or more files – as usual in
Windows – in the Explorer
NB!
However, "EXIT PROGRAM" does not end a
program running in the VLT. You can only
NB!
However, if the VLT stops at "FILE" → → → → → "EXIT
PROGRAM" then this can be due to the fact
Explorer Explorer Explorer. Explorer
