Parameter Lists - Danfoss FC 300 Programming Manual

2. How to Programme
2

2.19. Parameter Lists

FC Series
All = valid for FC 301 and FC 302 series
01 = valid for FC 301 only
02 = valid for FC 302 only
Changes during operation
"TRUE" means that the parameter can be changed while the frequency converter is in operation
and "FALSE" means that the frequency converter must be stopped before a change can be made.
4-Set-up
'All set-ups': the parameter can be set individually in each of the four set-ups, i. e. one single
parameter can have four different data values.
'1 set-up': data value will be the same in all set-ups.
Conversion index
This number refers to a conversion figure used when writing or reading by means of a frequency
converter.
Conv. index
Conv. factor
Data type
2
3
4
5
6
7
9
33
35
54
202
The encoder function in par. 17-61 is an electrical check of the
hardware circuit in the encoder system.
100 67 6 5 4
1 1/60 100000 100000 10000 1000
0
Description
Integer 8
Integer 16
Integer 32
Unsigned 8
Unsigned 16
Unsigned 32
Visible String
Normalized value 2 bytes
Bit sequence of 16 boolean variables
Time difference w/o date
MG.33.M2.02 - VLT
3 2 1 0 -1 -2
100 10 1 0.1 0.01
®
is a registered Danfoss trademark
FC 300 Programming Guide
-3 -4 -5 -6
0.00 0.000 0.0000 0.000001
1 1 1
Type
Int8
Int16
Int32
Uint8
Uint16
Uint32
VisStr
N2
V2
TimD
