6-51 Terminal 42 Output Min Scale
Range:
0%
118
Motor current
Torque rel to lim
Torque rel to rated
Power
Speed
Torque
Max Out Freq 0-20
mA
Output freq. 4-20 mA
Reference 4-20 mA
Feedback 4-20 mA
Motor cur. 4-20 mA
Torque % lim. 4-20
mA
Torque % nom 4-20
mA
Power 4-20 mA
Speed 4-20 mA
Torque 4-20 mA
Bus ctrl. 0-20 mA
Bus ctrl. 4-20 mA
Bus ctrl. 0-20 mA,
timeout
Bus ctrl. 4-20 mA,
timeout
Max Out Freq 4-20
mA
* [0 – 200%]
MG.33.M2.02 - VLT
Function:
Scale the minimum output of the selected analog signal at ter-
minal 42, as a percentage of the maximum signal value. E.g. if
0 mA (or 0 Hz) is desired at 25% of the maximum output value,
then programme 25%. Scaling values up to 100% can never be
higher than the corresponding setting in par. 6-52.
®
