Danfoss FC 300 Programming Manual page 166

2. How to Programme
[51]
[60]
[61]
2
[70]
[71]
[72]
[73]
[74]
13-43 Logic Rule Operator 2
Array [6]
[0]
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
13-44 Logic Rule Boolean 3
Array [6]
[0]
[1]
[2]
[3]
[4]
[5]
[6]
166
Comparator 5
Logic rule 4
Logic rule 5
SL Time-out 3
SL Time-out 4
SL Time-out 5
SL Time-out 6
SL Time-out 7
* DISABLED
AND
OR
AND NOT
OR NOT
NOT AND
NOT OR
NOT AND NOT
NOT OR NOT
False
True
Running
In range
On reference
Torque limit
Current limit
MG.33.M2.02 - VLT
Select the second boolean (TRUE or FALSE) input for the selec-
ted logic rule. See par. 13-01
Stop Event
13-02 ([70] - [74]) for further description.
Select the second logical operator to be used on the boolean
input calculated in par. 13-40, 13-41, and 13-42, and the boo-
lean input coming from par. 13-42.
[13-44] signifies the boolean input of par. 13-44.
[13-40/13-42] signifies the boolean input calculated in par.
13-40, 13-41, and 13-42. DISABLED [0] (factory setting). select
this option to ignore par. 13-44.
Evaluates the expression [13-40/13-42] AND [13-44].
Evaluates the expression [13-40/13-42] OR [13-44].
Evaluates the expression [13-40/13-42] AND NOT [13-44].
Evaluates the expression [13-40/13-42] OR NOT [13-44].
evaluates the expression NOT [13-40/13-42] AND [13-44].
Evaluates the expression NOT [13-40/13-42] OR [13-44].
Evaluates the expression NOT [13-40/13-42] and evaluates
AND NOT [13-44].
Evaluates the expression NOT [13-40/13-42] OR NOT [13-44].
®
is a registered Danfoss trademark
FC 300 Programming Guide
Start Event
([0] - [61]) and par.
