FC 300 Programming Guide
[16]
4-21 Speed Limit Factor SourceOption
Option:
*
[0]
[2]
[4]
[6]
[8]
[10]
[12]
[14]
[16]
2.7.3. 4-3* Motor Feedback Monitoring
The parameter group includes monitoring and handling of motor feedback devices as encoders,
resolvers etc.
4-30 Motor Feedback Loss Function
Option:
[0]
[1]
*
[2]
4-31 Motor Feedback Speed Error
Range:
300
*
RPM
Analog input X30-12
inv
Function:
Select an analog input for scaling the settings in par. 4-19 from
0% to 100% (or inverse). The signal levels corresponding to 0%
and 100% are defined in the analog input scaling, e.g. par.
group 6-1*. This parameter is only active when par. 1-00
figuration Mode
No function
Analog input 53
Analog input 53 inv
Analog input 54
Analog input 54 inv
Analog input X30-11
Analog input X30-11
inv
Analog input X30-12
Analog input X30-12
inv
Function:
Select which reaction the frequency converter should take in the
case a feedback fault is detected. The selected action will take
place if the feedback signal differs from the output speed with
more than specified in par. 4-31 during the time set in par. 4-32.
Disabled
Warning
Trip
Function:
[1-600 RPM] Select the max allowed tracking error in speed from the calcu-
lated and the actual mechanical shaft output speed.
®
MG.33.M2.02 - VLT is a registered Danfoss trademark
2. How to Programme
Torque Mode
is in .
2
Con-
89
