17-51 Resolver Input Voltage
Range:
*
7.0V
17-52 Resolver Input Frequency
Range:
10.0kHz
*
17-53 Resolver Transformation Ratio
Range:
*
0.5
17-59 Resolver Interface
Option:
*
[0]
[1]
2.18.5. 17-6* Monitoring and Application
This parameter group is for selecting additional functions when MCB 102 Encoder option or MCB
103 Resolver option is fitted into option slot B as speed feedback.
Monitoring and Application parameters cannot be adjusted while the motor is running.
17-60 Encoder Positive Direction
Option:
*
[0]
[1]
17-61 Encoder Signal Monitoring
Option:
[0]
*
[1]
[2]
Function:
[4.0 - 8.0 V] Set the input voltage to the resolver. The voltage is stated as
RMS value.
The value is stated in the data sheet for resolvers
Function:
[2.0 - 15.0 kHz] Set the input frequency to the resolver.
The value is stated in the data sheet for resolvers.
Function:
[0.1 - 1.1] Set the transformation ratio for the resolver.
The transformation ration is:
T
ratio
The value is stated in the data sheet for resolvers.
Function:
Disabled
Enabled Activate the MCB 103 resolver option when the resolver param-
eters are selected.
To avoid damage to resolvers par. 17-50 – par. 17-53 must be
adjusted before activating this parameter.
Function:
Clockwise
Counter clockwise Change the detected encoder rotation direction without chang-
ing the wiring to the encoder.
This parameter cannot be adjusted while the motor is running.
Function:
Disabled
Warning
Trip Select which reaction the frequency converter should take in
case a faulty encoder signal is detected.
®
