FC 300 Programming Guide
[46]
[47]
5-31 Terminal 29 Digital Output
Option:
[45]
[46]
[47]
This parameter only applies for FC 302.
5-32 Terminal X30/6 Digital Output (MCB 101)
Option:
*
[0]
5-33 Terminal X30/7 Digital Output (MCB 101)
Option:
*
[0]
2.8.5. 5-4* Relays
Parameters for configuring the timing and the output functions for the relays.
5-40 Function Relay
Option:
[1]
[2]
[7]
[8]
Bus ctrl. on at timeout Controls output via bus. The state of the output is set in par.
5-90. In the event of bus time-out the output state is set high
(On).
Bus ctrl. off at timeout Controls output via bus. The state of the output is set in par.
5-90. In the event of bus time-out the output state is set low
(Off).
Function:
Bus ctrl. Controls output via bus. The state of the output is set in par.
5-90. The output state is retained in the event of bus time-out.
Bus ctrl. on at timeout Controls output via bus. The state of the output is set in par.
5-90. In the event of bus time-out the output state is set high
(On).
Bus ctrl. off at timeout Controls output via bus. The state of the output is set in par.
5-90. In the event of bus time-out the output state is set low
(Off).
Function:
No operation This parameter is active when option module MCB 101 is moun-
ted in the frequency converter.
Follow the function stated in 5-3*.
Function:
No operation This parameter is active when option module MCB 101 is moun-
ted in the frequency converter.
Follow the function stated in 5-3*.
Function:
Relay 2 is included in FC 302 only. Par. 5-40 functions are as for
par. 5-3*, including options 36 and 37.
Par. 5-40 options are as for par. 5-30, including options 36 and
37. Relay 2 is included in FC 302 only. Relay 7, 8 and 9 are
included in MCB 105 Relay option module.
(Relay 1)
(Relay 2)
Relay 7
Relay 8
®
