8.4.2 D4h Terminal Dimensions
1
319 (12.6)
200 (7.9)
0.0
1
Mains terminals
2
Brake terminals
Illustration 8.23 D4h Terminal Dimensions (Front View)
MG38C202
Design Guide
3
Motor terminals
4
Ground terminals
