Exterior and Terminal Dimen...
VLT® AutomationDrive FC 302
8.10 E2h Exterior and Terminal Dimensions
8.10.1 E2h Exterior Dimensions
97
3X
13 (0.5)
(3.8)
8
8
2043
(80.4)
2002
(78.8)
1553
(61.1)
1393
(54.9)
912
(35.9)
394
(15.5)
698
(27.5)
Illustration 8.76 Front View of E2h
118
Danfoss A/S © 01/2018 All rights reserved.
MG38C202
