The front panel of the RFU has a LED indicator that shows the current status of the
unit.

Table 39: LED indications

Colour
Off –
Green Solid
Slow flashing
Slow flashing with flicker
of yellow
Slow flashing with red
Yellow Solid
Slow flashing
Slow flashing with flicker
of red
Alternate flashing with red
Red Solid
E ™ T R
NVOY RANSCEIVER EFERENCE
LED indications
Status
RFU is switched off
RFU is ready and operational
RFU is ready, but has no control points connected
RFU needs to be switched off then on again to activate
changes
RFU is experiencing a non-fatal error
RFU is initialising
RFU is off line due to internal reconfiguration
RFU is in bootloader mode
RFU is upgrading firmware
RFU requires attention or servicing
