15-way GPIO connector

The 15-way connector is on the back panel of the desk console. It is used to interface
to a variety of third-party products.
Figure 81:
Pin no. Function
1 Not implemented
2 Not implemented
3 Not implemented
4 Ground
5 Not implemented
6 Not implemented
7 Not implemented
A rail protected
8
(2 A maximum)
9 Not implemented
10 Not implemented
11 Morse
12 Not implemented
13 Not implemented
14 Not implemented
15 Not implemented
E ™ T R
NVOY RANSCEIVER EFERENCE
Front view of the 15-way GPIO connector
9
1
M
ANUAL
15
8
Input/output
Output
Input
C
ONNECTORS ON THE DESK CONSOLE
Signal level
0 V
+13.6 V nominal
5 V TTL logic active low
C
ONNECTORS
373
