Overview of modes

Information about the modes available in the transceiver is stored in User Data >
Modes. A mode specifies a combination of a sideband (for example, USB or LSB)
and IF filter values (that is, bandwidth and centre frequency).
Each channel must have at least one mode. You may want to select several modes for
each channel depending on the modes available to you.
Related links:

Available modes

The transceiver comes with a set of standard modes, and other modes may be added
with software options.
transceiver. The modes that appear for selection with a channel are the allowed modes.

Table 11: Modes

Name of Sideband
mode
USB USB
LSB LSB
AM AM
AM AM
USBW USB
LSBW LSB
USBXW USB
LSBXW LSB
UMCW USB
LMCW LSB
CW USB
282
Overview of channels on page 118
Table 11
Rx/Tx IF centre
Rx/Tx
Rx/Tx
Rx
Tx
Rx/Tx
Rx/Tx
Rx/Tx
Rx/Tx
Rx/Tx
Rx/Tx
Rx/Tx
lists the modes that may be available within your
IF width
(Hz) (Hz)
1500 2400
1500 2400
0 6000
1500 2400
1675 2750
1675 2750
1800 3000
1800 3000
900 500
900 500
900 500
E
Standard/Option
Standard
Standard
Standard
AM filter option
2750 Hz filter option
2750 Hz filter option
3000 Hz filter option
3000 Hz filter option
500 Hz filter option
500 Hz filter option
500 Hz filter option
