Codan Envoy Reference Manual page 170

HF
NETWORKS
W HF
ORKING WITH NETWORKS
1
1
1
1
1
1
1
1
1
1
1
1
1
1
148
NOTE: Do not enter a self address that ends with one or more zeros.
Zeros are used to indicate that calls are to be made to groups of
stations in a Codan Selcall HF network.
to move to the Scan Tables entry.
Press
To select a scan table:
• Press to view the list of available scan tables.
• Press or to scroll to the scan table that you want to use, then
press OK.
• Press (Save).
Press to move to the Global entry.
If you want the information for this HF network to be used for all channels
programmed in the transceiver, select the On check box.
Press to move to the Preamble Length entry.
If the Auto value is not suitable, press
length by 1 sec, up to a maximum of 50 sec/HF network.
Press to move to the Send Preamble entry.
Press or to scroll through the following values:
• To send preamble with every call made via this HF network, select
Always.
• To send preamble only when your transceiver is scanning when you start
a call, select Only when scanning.
If you are adding an HF network with an ALE/CALM call system:
to move to the Sounding Interval entry.
• Press
• Press or to select the sounding interval that you want to use, or disable
sounding.
to move to the Privacy Mode entry.
Press
Press or to scroll through the following values:
• To make calls between two stations using a Codan protocol with special
formatting, select None.
• To encrypt data in calls between two stations using an agreed privacy
password, select Group.
• To send AMD messages in ALE calls (MIL-STD-188-141B ALE only),
select Plain.
Press to move to the Privacy Password entry.
To enter a privacy password:
• Press .
• Enter the password that you want to use in the New Password field.
• Press (Save).
to move to the Rx Only entry.
Press
repeatedly to increment the preamble
E ™ T R
NVOY RANSCEIVER
M
EFERENCE ANUAL
