P
HONE LINKS
O
VERVIEW OF PHONE LINKS

Overview of phone links

A phone link is a bundle of information that defines how your station communicates
with a telephone station. A telephone station comprises a Codan HF transceiver that
is connected to a radio/telephone interconnect unit. This unit routes Phone calls from
HF transceivers to the public telephone network, and vice versa.
The address of the phone link station that you use, the HF network and the optional
preferred channel/mode that you use to make a Phone call are stored in the entries for
a phone link.
When you make a Phone call, the transceiver uses the information stored in the phone
link to make the connection to the telephone station, which then places the call to the
telephone number provided.
Figure 43
detail in the sections following.
Figure 43:
152
shows information that is stored for a phone link. Each item is described in
Information for a phone link

Phone Links

NorthTI1 HF Network:
Selcall Address:
Preferred Channel:
NorthTI2 HF Network:
ALE Address:
Preferred Channel:
Selcall
1523
Ch 05/USB
CALM
1524
<None>
