Entries for a peripheral

Related links:

RFU 15way Mode

The RFU 15way Mode entry sets the mode in which the RS232 15-way serial port
operates. This entry is only available if you are setting up the 15-way connector on the
RFU for a user-defined peripheral device.
If the port is:
•
•
•
•
•
Default value:
E ™ T R
NVOY RANSCEIVER EFERENCE
RFU 15way Mode on page 197
RFU 15way Speed on page 198
RFU 15way Startup on page 198
RFU Average ALC on page 198
RFU ALC Rate on page 198
RFU Audio Type on page 198
RFU AGC on page 199
RFU PTT Beep on page 199
RFU Mute Extend on page 199
RFU Mute Off After PTT on page 199
RFU Sidetone Volume on page 200
RFU Secure Audio on page 200
RFU Quiet Line on page 200
RFU 15way MIL/STANAG 2G Data Interface on page 200
RFU 15way 2.4 kbit/s Data Modem Interface on page 201
RFU 6way Mode on page 201
RFU 6way Speed on page 201
RFU 6way Startup on page 201
RFU 6way MIL/STANAG 2G Data Interface on page 202
not in use, select None
receiving GPS information, select GPS
controlling and monitoring the transceiver, select CICS
connected to a modem, select Data
connected to a radio/telephone interconnect unit, select 3033
None
M
ANUAL
P
ERIPHERALS
E
NTRIES FOR A PERIPHERAL
197
