Codan Envoy Reference Manual page 156

S
CAN TABLES
W
ORKING WITH SCAN TABLES
1
1
1
1
1
1
1
1
Adding channels to a scan table
When you are adding or editing a scan table, you may want to add extra scan channels
to those already in the scan table. When you use the Add Chan option, you view a
list of the channels in the transceiver that have not yet been added to the scan table that
you are currently viewing. You may also duplicate a channel. If the same mode is used
for this duplicate, then the dwell time for this channel is doubled. Alternatively, you
can select a different allowed mode for this channel.
To add channels to a scan table:
1
1
1
1
1
1
1
134
If you want the channels in the scan table to be scanned for voice signals
regardless of the types of HF networks to which this scan table is allocated,
press OK to select the On check box.
Press to move to the Channel Dwell Time entry.
To change the channel dwell time from the Auto value for the HF networks
allocated to the scan table:
• Press repeatedly to increment the dwell time per channel by 25 msec,
up to a maximum of 10 sec per channel.
• Press and to move the cursor to a specific digit, then enter a number
via the keypad, if required.
Press to move to the HF Networks entry.
The HF Networks entry is read-only. It shows in which HF networks this scan
table has been allocated.
to move to the Data entry.
Press
If you want the channels in this scan table to be scanned for data signals in
scanning Selcall systems that use a 3012-compatible HF data modem, press OK
to select the On check box.
If you want to review the information that you have entered, press
move through the entries.
Press (Save) to save the information.
From the main menu, select
Press or to scroll to the scan table in which you want to add a channel, then
press OK.
Press to move to the Scan Channels entry.
Press to view the list of channels that are already added to the scan table.
(Options), scroll to Add Chan, then press
Press
Press or to scroll to the channel that you want to use, then press OK.
Press or to select the mode that you want to use.
(User Data), then
E ™ T
NVOY RANSCEIVER
or to
(Scan Tables).
(Select).
R M
EFERENCE ANUAL
