ALARMS – REMOTE DISPLAY
ALARMS

REMOTE DISPLAY

Note: The Remote Display must always be connected to the control box. Otherwise, the whole system
doesn't work.
The message above appears if there's a problem in the communication between REMOTE DISPLAY and CONTROL
BOX (or the REMOTE DISPLAY is not connected at all).
ALARMS: REMOTE
DISPLAY
LEDs are all OFF
ALARMS: REMOTE
DISPLAY
Some LEDs ON or start-
up test working (all LEDs
are switched ON in
sequence when powered
up).
EZDigPro
Alarms – Remote Display
No Connection between Control Box and Remote Display or
Remote Display is not Working
Check connection
Clean connectors
Check power supply voltage
Communication Error between Control Box and Remote Display
Clean connectors
Restart the control box
- 94 -
Remote Display powers up together
with the control box.
Power button on it has no function.
