Remote Display

REMOTE DISPLAY
All the default values used to switch OFF/ON the LEDs depending on
the actual depth, can be customized with:
Dead Band Selection
User Parameters
Other functions of the remote display LEDs
Depth Green LED and
Reach Green LED
flashing alternately
Depth Green LED flashing
All red LED flashing
together
EZDigPro
Red: too high, move the bucket down.
Depth
Page 74
Page 78
Searching sensors at control box start up
Remote display in sensor assignment mode
Sensors Alarm (sensor not synchronized)
Green: on grade.
Red: too low, move the bucket up.
Advanced Mode
Reach
- 63 -
User & Calibration Manual
