Zeroing the Target Reach

A
Bucket on grade:
Zero reach.
Position the bucket on the ground on a desired reference point and keep pressing the
seconds to zero the reach value.
Now the reach value will be zero at that distance (even in other depth positions) and the distance value to that point
will be shown if the bucket is further away (positive) or closer (negative) to the cab.
A
Bucket on the reach
zero reference
EZDigPro
REACH
A
Bucket too far,
Positive reach
- 80 -
Advanced Mode
key for a couple of
A
Bucket too close.
Negative reach
