[usage] User Settings
EZDigPro
Height MAX
Change the icon with
Function disabled.
There's no maximum height set.
Setting in Progress
Move the boom to the maximum height that you want or can reach
depending on your work environment.
Press
Enter
See dedicated page for more details.
Function enabled.
When limit is reached, there will be a warning screen and alarm.
Memory Function
Memory function not in use.
Set Reference:
Memory function point acquisition at 1
Keep Reference:
Reference point is saved, before moving the machine and taking same
reference point at 2
3
Memory function is in use (depth affected by the function).
See dedicated page for more details.
to acquire this point as maximum height.
nd location.
- 90 -
Advanced Mode
st location.
