[controlbox] Key Identification
-
-
+
+
Enter
Enter
0
0
%
%
Press once:
To enable the laser acquisition (reference the depth value to the laser plane)
Press & hold:
To set a depth value in correlation to the laser plane height
Zeroing function
To zero the depth or reach value.
To exit any menu.
Press once to cycle through the horn settings: Off, On, Loud.
Enabling the speaker enables additional on-grade audio indication:
On-grade: Continuous tone
Too high or too low: Beeping tone
Press & hold to access the Dead Band setting page
