Table Of Contents - Agatec EZDigPro User & Calibration Manual

Contents
Introduction
System Functionality..............................3
System Components...........................4-6
First Time Setup...................................7
Components Installation
Control Box & Remote Display............8-10
Sensors........................................11-17
Control Box
System Start-Up.............................18-19
Keypad Identification....................... 20-21
Calibration Setup
Part Names................................... 22-23
Access to Calibration Functions..............24
Calibration Menu.................................25
Sensor Assignment.........................26-27
Machine Selection...............................28
Calibration Selection............................29
Automatic Calibration
Sensors Position.............................30-31
Dog Bone......................................32-33
Booms/Bucket................................34-40
Laser Receiver....................................41
Manual Calibration
Booms & Dog Bone.........................43-51
Bucket..........................................51-53
Laser Receiver....................................54
Measuring Tips.....................55-57
Laser Speed Compensation....58-59
EZDigPro
Usage
Display - Simple Mode..........................60
Display - Advanced Mode.................61-62
Remote Display...................................63
Zeroing the Target Depth..................64-65
Set the Depth Reference........................66
Slope Setting.................................. 67-68
Laser Function.................................69-72
Bucket Selection..................................73
Dead Band Selection............................74
User Options Menu...........................75-76
Unit of Measure....................................77
Parameters.....................................78-79
Zeroing the Target Reach...................... 80
Set the Reach Reference.......................81
Memory Function.................................82
Maximum Height Function......................83
Maximum Depth Function......................84
Profile Setting.................................85-88
User Settings..................................89-90
Troubleshooting
Battery Level.......................................91
Sensor Reception.................................92
Alarms
Sensors....................................93
Remote Display..........................94
Specifications..............................................95
Safety
EMC, FCC, CDRH............................96-97
Warranty & Contact Information.................98-99
- 2 - User & Calibration Manual
