First time setup

Choose where to install the system's components on your machine and proceed with
Choose where to install the system's components on your machine and proceed with
Do not place the sensors on the elements until completing the assignment procedure.
Do not place the sensors on the elements until completing the assignment procedure.
Power up the control box and assign the sensors to the correct machine elements
Power up the control box and assign the sensors to the correct machine elements
- Dog Bone calibration (if the Bucket sensor has been mounted on the Dog Bone)
- Dog Bone calibration (if the Bucket sensor has been mounted on the Dog Bone)
- Booms/Bucket calibration
- Booms/Bucket calibration
- Laser Receiver calibration (if the system will be used in combination with a laser transmitter)
- Laser Receiver calibration (if the system will be used in combination with a laser transmitter)
EZDigPro
How to set up the system for your machine
control box and remote display installation.
control box and remote display installation.
(see Components Installation section)
(see Components Installation section)
where they will be attached.
where they will be attached.
(see Sensor Assignment section)
(see Sensor Assignment section)
Fix the sensors in their final position on the assigned elements.
Fix the sensors in their final position on the assigned elements.
(see Components Installation - Sensors section)
(see Components Installation - Sensors section)
System Calibration
System Calibration
(see Calibration section)
(see Calibration section)
Ready!
Ready!
