Agatec EZDigPro User & Calibration Manual page 71

[usage] Laser Function
Short press
Beam not caught within 15 sec
or pressed
Return to previous
screen
(laser function status
as before)
EZDigPro
LASER RECEIVER ENABLED
Beam catch within 15 sec.
DoubleLS parameter:
ON (default) OFF
Stop the machine
movement when the
laser beam is
intercepted and wait
for a second static
laser beam
acquisition with the
laser sensor over
the beam.
Return to previous
screen
(laser function in use)
- 71 -
Press & hold
LASER HEIGHT:
Set the known
0.000
laser height to your
Confirm
reference – target
height distance
pressed
Return to previous
screen
(laser function
disabled)
User & Calibration Manual
