Part Names

EXCAVATOR PARTS USED IN CALIBRATION
Conventional Boom – 3-Sensor Machine
Boom 2
Boom 1
Bucket
Chassis
Boom 2
Boom 1
If you have an articulated boom and you lock it to the main boom and use it as a
single boom, the system can be set and used as a 3-sensor machine.
EZDigPro
- 22 -
User & Calibration Manual
