Agatec EZDigPro User & Calibration Manual page 50

[manual calibration]
BOOM 3 - ANGLE
Move the cursor to highlight parameter
Press and you will see the new offset value acquired.
Enter
EZDigPro
Boom 3
BOOM 3 CALIBRAT.
BOOM 3 CALIBRAT.
Side
Side
Length
Length
Angle
Angle
-Offset
-Offset
-Actual
-Actual
Fig.8
Angle
, set the exact boom value in degrees referring to Fig.8
- 50 -
L
L
6.600
6.600
30.0
30.0
25.0
25.0
0.0
0.0
User & Calibration Manual
