[usage] Display – Advanced Mode
-
Press to change the page.
EZDigPro
Depth
Reach
Slope
MIN
MAX
Main operator screen shown at system start-up.
Depth, reach and actual slope set are shown.
Note: The advanced mode may be enabled
through the user menu, by changing the value for
"Advan.Mode" from "OFF" to "ON".
Second operator screen with status icons.
Slope
Reach
Third operator screen with a dynamic bucket icon
(reflects the real bucket angle). Depth & Slope
setting/visualization plus a small depth graphical
bar.
