User Options Menu

USER MENU
USER MENU
Contrast:
Contrast:
Language:
Language:
UnitMeasur
UnitMeasur
Resolution
Resolution
Advan.Mode
Advan.Mode
Machine
Machine
Parameters
Parameters
Sensors Check
Sensors Check
Calibration Menu
Calibration Menu
Machine
Indicates the machine calibration that's in use. It's possible to store up to 5 different calibrations (machines) to quickly
recall a previously set calibration (control box / sensors moved to another machine).
Note: There is a total of 9 buckets per machine available.
Parameters
Page with more parameters that affect the behavior of the system
Description in the followings pages.
Sensors Check
Dedicated page showing the raw angle and battery value received from the sensor.
Calibration Menu
To calibrate the system, described in the calibration section.
This section can be password protected depending on the system installer choice.
EZDigPro
60
60
EN
EN
M
M
.00
.00
OFF
OFF
1
1
Page 91- Troubleshooting
- 76 -
Page 78
section
Page 22- Calibration
section
User & Calibration Manual
