11 LX Joy

11.1 General

LX Joy is an ergonomically designed, leather covered remote stick handle for gliders. As seen by the pilot,
it consists of 5 buttons and a navigation switch on the front side, one button on the rear side, a built-in
electronic circuit and wiring.
The internal diameter of the bore can be 19,1 mm, 20,1 mm or 24,3 mm. It is important to point out the
dimension when ordering your remote stick. (If the glider type is specified when ordering LXN will know
what size is required)
In order for LX Zeus to work with LX Joy, the software version on LX Zeus should be at

11.2 Button description

Short press: VARIO
Long Press: SETUP
Short press: ESC
Long Press: ESC
NOTE!!
least 3.2.2 or higher.
NORMAL MODE (LED OFF)
(as seen by the pilot)
Short press: PTT
Long Press: PTT
LX Zeus v4.0.2
Short press: FN
Long Press: /
Short press: TSK
Long Press: MOVE
