LX Navigation Zeus User Manual page 49

The transfer procedure is as follows:

Insert USB stick
Press SETUP button

 Select Transfer
Press Zoom rotary knob


Select what is to be transferred (example
airfields), and press Zoom rotary knob

Select "transfer file from USB" and press the
Zoom rotary knob

Example: all .af files stored on the USB stick will
be shown

Select the file of interest and press on the Zoom
rotary knob

The transfer will follow and a window and a green
check will show

Go to Select, press Zoom rotary knob and select
the file

The file is now activated (green check at select
row)
How to delete files (APT, TP, AS):
Files can be removed from the LX Zeus using the Delete
internal files command. The command is executable for
Airports, Turn points and Airspace.
2.3.5.1 Transfer Airport data
The airport database in .af format for the Zeus is at
webpage www.lxnavigation.com. It is free of charge with
no code required.
2.3.5.2 Transfer Turnpoint data
The turnpoint data should be included in a file with
extension .cup or .cupx.
Three TP files can be active at the same time. Turn-points
of any of the three files will be available for navigation
without any limitations.
Transfer specific tasks
Tasks can be uploaded to Zeus via a USB key.
Important!
Only one .af file can be active at a
time. After the transfer has finished
you should activate using Select
function. A green check means the file
is active.
Note!
The first TP file is also called TASK file,
which means, if you want to import
tasks from file, that you have to select
your file at TP/Task/Eos. This file is also
sent to LX Eos. In backup mode, you can
use points from this file to navigate.
Note that only the first 1000 points are
sent to LX Eos.
