3.3.1

APT selection from NEAR function

LX Zeus also offers NEAR function. After a long press on
the SELECT/NEAR button, the nearest Landable points
and User markers will be offered. The list includes
airports from the airport database, turn-points that are
declared as landable and Markers.
Note!
Selection is limited to 200
nearest points

3.4 TP mode (navigation to turnpoints)

TP and APT modes are similar in structure. The only important difference is that the navigation is
towards turn-points that are stored in the turn-point files. Turn-point files (.cup or .cupx) should be
uploaded via a USB stick. (See Setup>Transfer for details.) An almost unlimited number of .cup/.cupx
files can be uploaded. Because turn-points can have different attributes the symbols that represent the
various types are different.
st
TP mode consists of three navigation pages (main page is map navigation page, 1 subpage with
nd
information about selected airport and glide path, 2 subpage with a map and a 3D view (with AHRS) or
vertical profile. Switch between pages by pressing the SUBP button.
st
If using .cupx files turn-point images are shown on 1 subpage. A .cupx file can be prepared on a PC or on
LX Zeus. To add pictures to turn-points use Select TP menu. On the bottom of the menu is shown the
Upload photo screen button. Use it to transfer pictures from an USB stick to the selected turn-point.
Note: The second subpage (3D terrain) can be disabled (see Setup>User interface).
