LX Joy

The LX Joy (short for Joystick) is a remote control unit for the LX
the aircraft's ight control stick. Using the Joy with the LX
settings, without touching the LX
Please note that the LX Joy is shared between the LX
all of the buttons are required for the full operation of the LX
without functions (VOL).
In general, the Joy input interface consists of ve front-facing push buttons, a central penta-
directional (up, down, left, right and push) joy button, a front facing LED and a SC push button
on the back side (facing the instrument panel).
The central button is used for main navigation throughout the LX
ing of both the left and right push-rotary knobs and pressing the right push-rotary knob, in the
following way:
• Left/Right - mimics turning the right push-rotary knob
• Up/Down - mimics turning the left push-rotary knob
• Pressing - mimics pressing the right push-rotary knob
The MC button will mimic the pressing of the MC button on the LX
Device manual
LX Joy
k itself.
Figure .
