How To Select An Airport - LX Navigation Zeus User Manual

The RWY orientation shown matches the real situation. Extended Airport data is available in the lower
section of the second subpage. Pressing the 1-4 button on the second subpage will bring up some
additional screens (wind profile, thermal history, etc.).

3.3 How to select an airport?

Airport selection is available from any mode of operation
and also from any subpage. Press the SELECT button
(short press) and the selected menu will open. Use screen
button APT with a short press of TSK/MOVE to start the
selection dialogue. If already on the TSK navigation page,
give a short press on the Volume rotary knob which is a
shortcut to the APT selection menu.
Reachable APTs from the current position are shown in
green, non-reachable are labelled red.
Scroll with the Zoom rotary knob to select a filter such as:
Country, Name, Distance, and Track or Arrival altitude to
reduce the number of offered Airports. If using a sort by
distance filter, then it is not possible to use a named filter.
Using a country filter will show airports only from the
selected country. After the airport of interest is found
confirm the choice with a short press on the Zoom rotary
knob. The APT screen will open giving navigation to the
chosen destination.
When using the Name filter, input first letters of the
airport name. Use the Zoom rotary knob to scroll and
press it for confirmation. You don't need to input all
characters, just first two or three and after that you can
go on by pressing the Zoom rotary knob. Input of more
characters reduces the number of possible airports.
Note!
LX Zeus v4.0.2
59 | P a g e
